Slot Drain Pipe
Slot Drains provide a high volume water flow, with a narrow surface opening. This is perfect for not only a sleek look and finish, but also with the ability to move the same amount of water and no larger space or opening on your surface area. Comes in three options, our Micro Slot system, Slot Drain system, and Wall Slot system.
Slotted Drain Pipe is a practical, aesthetically pleasing drainage inlet product for the efficient removal of surface water and sheet flow on streets and highways. It also is widely used in parking lots and similar locations to remove sheet flow without complex multiple grades, catch basins, or water channeling devices.
Eight Slot French Drain Pipe
Slotted Drain Pipe is fabricated by welding a narrow section of grating in a continuous slot cut in the top of a corrugated steel pipe. A trapezoidal or straight-sided grate with reinforcing spacer plates is welded in place to form a 1 3/4″-wide slot opening which collects runoff and channels it to the pipe below to form a continuous grate inlet.
- Slot Drain changed surface drainage forever by providing the first pre-sloped, prefabricated drain system. The linear slot eliminates traditional grates that can be weak, trap bacteria and are difficult to clean. Slot Drain is applicable wherever floor or ground surfaces are subject to fluids, or have frequent cleaning requirements.
- DURASLOT pipe, as manufactured and distributed by ADS, Inc., shall have a smooth interior and annular exterior corrugations with an aluminum slot grate frame mounted longitudinally along the length of the pipe to accept the grate while maintaining the original pipe diameter. 4- through 10-inch (100 to 250mm) pipe shall meet AASHTO M252, Type S.
The benefits of slotted drain pipe include:
- Efficiently removes surface water
- Design improves hydraulic efficiency and provides for easier maintenance
- Wide variety of applications
- Curb inlets
- Airport aprons, taxiways, hangars and de-icing areas
- Railroad and intermodal facilities with heavy axle loads
- Shoulder and median barrier drains
- Inlet system across driveways
- Pedestrian thoroughfares, malls and bicycle paths
- Ground-level floors with drainage requirements
- Parking lots and other continuous paved surfaces
- Sidelines of playing fields and stadiums
Scope
This specification describes 4- through 36-inch (100 to 900 mm) ADS DURASLOT pipe for use in surface drain applications.
Pipe Requirements
DURASLOT pipe, as manufactured and distributed by ADS, Inc., shall have a smooth interior and annular exterior corrugations with an aluminum slot grate frame mounted longitudinally along the length of the pipe to accept the grate while maintaining the original pipe diameter..
- 4- through 10-inch (100 to 250mm) pipe shall meet AASHTO M252, Type S.
- 12- through 36-inch (300 to 900 mm) pipe shall meet AASHTO M294, Type S or ASTM F2306.
- Manning’s “n” value for use in design shall be 0.012.
The aluminum slot grate frame shall be manufactured from 0.063” tempered commercial aluminum meeting the requirements of ASTM B209, consisting of two parallel plates separated by spacers spanning the slot on 6” centers. The grate shall be ½ - #13 galvanized steel. The grate shall have a diamond-shaped opening and be ADA compliant. The flange at the bottom of the aluminum slot grate frame shall be riveted to the pipe with a minimum of two rivets per linear foot.
4 Slot French Drain Pipe
Fittings
Slot Drain Pipe
DURASLOT fittings shall be modified from fittings which conform to AASHTO M252, AASHTO M294, or ASTM F2306.
Installation
8 Slot Drain Pipe
Installation shall be in accordance with ADS recommended installation instructions. Contact your local ADS representative or visit www.ads-pipe.com for a copy of the latest installation guidelines.
